background image

69

Replacement Parts Table

Common parts

Symbol Part

Name

Code

No. Specification Manufacturer

X1/X2 Relay

2-05-000-0013 AHN36006

Matsushita

OH

Independent overheating
prevention device

2-10-011-0002 PAS3K1-0YB0Y

Yamato

Scientific

CT Current

transformer

2-17-001-0002

CTL-6-S-400

URD

TH1/TH2

Temperature sensor
(K thermocouple)

1-16-003-0054 LCK-M1-2000-M

Yamato

Scientific

CONT

PLANAR board

1-24-000-0108

IV CR2

FCJ

PIO

Display circuit board

LT00027240

PIO12

Yamato Scientific

FM1/FM2 Motor

2-14-000-0047

DC24V 10W CCW

Yamato Scientific

DS1/DS2 Door

switch

2-05-000-0054 LAB1L

OMRON

DC1/DC2

RA1/RA2

Fan controller

2-14-000-0045

DC10V-24V

Yamato Scientific

DNF400

Symbol Part

Name

Code

No. Specification Manufacturer

ELB

Earth leakage breaker

2-06-005-0001

BJS1532N

Matsushita

H

Heater

DNF40-30020

100V 1.25kW

Yamato Scientific

TF Transformer

2-18-000-0040

CR2 100V

Yamato Scientific

TM

Terminal block

2-07-023-0001 MO11-0FX 4P

TOYO

SSR SSR

LT00028423 SSR-01

Yamato

Scientific

Power cord

LT00008924

T2-3c

Yamato Scientific

DNF410

Symbol Part

Name

Code

No. Specification Manufacturer

ELB

Earth leakage breaker

LT00028200

BJS1032S1Z

Matsushita

H

Heater

DNF40-30270

200V 1.25kW

Yamato Scientific

TF Transformer

2-18-000-0042

CR2 200V

Yamato Scientific

TM

Terminal block

2-07-023-0001 MO11-0FX 4P

TOYO

SSR SSR

LT00028423 SSR-01

Yamato

Scientific

Power cord

2-13-001-0008

T2-3b-0

Yamato Scientific
