115

I/O store for a WI-I/O-EX-1-S-12 Expansion I/O module

0001 + Offset

0008 + Offset

DIO Outputs 1 - 8

10001 + Offset

10008 + Offset

DIO Inputs 1 - 8

10019 + Offset

Modbus Error indication for WI-I/O-EX-1-S module

10020 + Offset

Detected indication for this WI-I/O-EX-1-S module

30001 + Offset

30008 + Offset

Inputs AIN 1

– AIN8

30017 + Offset

Modbus Error Counter for this WI-I/O-EX-1-S module

30018 + Offset

Modbus Last Error Code for this WI-I/O-EX-1-S module. (Section 5.1.3

30019 + Offset

Modbus Lost Link Counter for this WI-I/O-EX-1-S module

30020 + Offset

Module type (0x0201) = 513. / Error Status

40009 + Offset

40016 + Offset

Pulsed Output target 1

– 8 (1 register per output)

I/O store for a WI-I/O-EX-1-S-13 Expansion I/O module
