108
RS232 Port EIA-562 (RJ45 Connector)
RS485 Port 2-Pin Terminal Block – Non-Isolated
(6)
Data Rate (Bps) 1200, 2400, 4800, 9600, 14400, 19200, 38400, 57600, 76800,
115200, 230400bps
Serial Settings 7 / 8 Data Bits; Stop/Start/Parity (Configurable)
Protocols and Configuration
System Address ESSID; 1
– 31 Character Text String
Protocols Supported TCP/IP, UDP, HTTP, FTP, TFTP, TELNET, MODBUS RTU
Master/Slave, MODBUS-TCP Client/Server
User Configuration All User Configurable Parameters via HTTPS
Configurable
Parameters Unit details, I/O mappings and parameters, radio settings, for
more refer to user manual.
Modbus TCP/ RTU Gateway
Embedded Modbus Master/Slave for I/O transfer
Security Data Encryption
– 256bit AES. Secure HTTP Protocol
LED Indication/Diagnostics
LED Indication Power/OK; TX/RX; RS232; RS485; Digital I/O; Analog I/O
status
Reported Diagnostics RSSI Measurements (dBm), Connectivity Information/Statistics,
System Log file
Network Management Optional Network Management System
Compliance
EMC FCC Part 15; EN 301 489; AS 3548
RF (Radio) FCC Part 15.247; AS 4268.2 ; RFS29 NZ
Hazardous Area CSA Class I, Division 2; ATEX; IECEx Na IIC
Safety IEC 60950 (RoHS Compliant)
UL UL Listed
General
Size
180 x 150 x 35 mm (5.91” x 7.09” x 1.38”)
Housing IP20 Rated High Density Thermoplastic
Mounting DIN Rail
Terminal Blocks Removable; Max conductor 12AWG (2.5 mm2)
Temperature Rating -40 to +60°C; -40 to +140°F
Humidity Rating 0 – 99% RH Non-condensing
Weight 0.5kg (1.1lb).
Power Supply
Nominal Supply 10.8 to 30Vdc; Under/ Over Voltage Protection
Average Current 220mA @ 12V (Idle), 110mA @ 24V (Idle)
