111
Appendix B: I/O Store Registers
“Output Coils”
0001
0008
Local DIO1 – DIO8 as Digital Outputs.
0009
0020
Spare
0021
0500
Space for locally attached WI-I/O-EX-1-S Expansion I/O modules. 20
register per module address, maximum number of modules is 24
(See Appendix C: below for details)
0501
3000
General Purpose Bit Storage – Used for:
Staging area for data concentrator
Fieldbus Mappings storage
Force Mapping registers (assigned in Config)
3001
10000
Not Available
“Input Bits”
10001
10008
Local DIO1
– DIO8 as Digital Inputs.
10009
10020
Setpoint status from Analog inputs 1 through 12.
10021
10500
Space for locally attached WI-I/O-EX-1-S Expansion I/O modules. 20
register per module address, maximum number of modules is 24
(See Appendix C: below for details)
10501
10595
WIBMesh - General Purpose Bit Storage: Staging area for data
concentrator Fieldbus Mappings storage
WIBNet - Remote Comms Fail Indication – corresponds to unit address,
e.g. Remote Address 1 - 95
10596
12500
Continuation of General Purpose Bit Storage: Staging area for data
concentrator Fieldbus Mappings storage
12501
30000
Not Available
