Mnc2, Mxc2, Flow – Titus Sensor STE-8001 and STE-8201 User Manual
Page 26

KMC Controls
Revision A
Commissioning functions
Setting the airflow setpoints
26
Set the minimum
limit for indoor air
quality ventilation
1. Press the or buttons to set the
minimum limit for ventilation
airflow. The setpoint will change in 1
CFM increments.
2. Press the button to save the
setpoint and advance to the next
function.
Set the maximum
limit for indoor air
quality ventilation
1. Press the or buttons to set the
maximum limit for ventilation
airflow. The setpoint will change in
1 CFM increments.
2. Press the button to save the
setpoint and advance to the next
function.
Advance or exit
1. Press the or buttons to select
one of the following:
•
STPT
,
BOX
, or
ADVC
options
•
BACK
to choose another
commissioning function
•
EXIT
to return to the temperature
display.
2. Press the button to select the next
function.
Procedure to set the airflow setpoints (Continued)
Procedure
Steps
STE display
Set
Point
OO
MNC2
Set
Point
3SO
MXC2
Set
Point
FLOW
