FACTORY DEFAULTS
Master Programming Code………..………………….….…...123456
Entry Code Length……………………………………….……..4 digits
Request-to-exit Output Relay……………………….........Main Relay
Alarm Shunt Output….………………………………….........Disabled
Forced Entry Output……………………………..…………..Output #3
Door Ajar Output…………………………………..………...Output #4
Main Relay On Time………………………………...……..60 Seconds
Auxiliary Relay On Time………………………………...…60 Seconds
Solid State Output #3 On Time………………………..….60 Seconds
Solid State Output #4 On Time…………………………...60 Seconds
Door Sense/Inhibit Input…………………………...……..Door Sense
Keypad Lockout Output………………………………..…….Disabled
Keypad Active Output………………………………..…..…..Disabled
Beeper Sounds When Key Pressed……………………...………Yes
Beeper Sounds During Relay #1………………………..…...…….No
Beeper Sounds During Relay #2……………………………...…...No
Beeper Sounds During Output #3……………………………….....No
Beeper Sounds During Output #4……………………………........No
Keypad Lockout Count……….………......….3 Tries Before Lockout
Anti-Passback Time………………..……...……….No Anti-Passback
Auto-Relock…………………………………...………….………….On
BASIC PROGRAMMING
When the 918 EntryCheck™ is in Programming Mode, both
indicators will turn off until programming begins. After a
programming option number is entered, the yellow indicator will
blink. This shows that the 918 is ready to accept the new
programming data. After the new data entry is complete, the
yellow indicator will flash while the data is being stored. The
green indicator will light if the data is accepted. The red indicator
will light if any programming data is entered incorrectly, and the
command will have to be fully re-entered.
Entering Programming Mode
The 6-digit Master Programming Code (default = 123456) is used
to enter Programming Mode.
Press: # 9 # Master Code
Master Code = the current 6-digit Master Programming Code
Exiting Programming Mode
Press:
* *
#
The red indicator will light after exiting Programming Mode
Note: The 918 will automatically exit Programming Mode after
two minutes of inactivity
Re-entering a Command After a Mistake
If the red indicator lights, signaling an incorrect entry, or an
incorrect key is pressed during programming, to clear the keypad
and re-enter the command:
Press:
*
9 #
Setting Entry Code Length Default: 4 digits
Press: 0 3 # Length #
Length = 1-6 for entry code length
Note: If the Entry Code Length is going to be changed from the factory
default of 4 digits, make this change first before programming any entry
codes.
Adding a New Entry Code
Press: 0 1 # Code # Code # Relay #
Code=The new entry code: 1-999999, depending on code length
Relay=Relay output entry code will activate:
1=Main Relay 2=Auxiliary Relay 3=Both Relays
10=Relay #1, toggled 20=Relay #2, toggled 30=both Relays toggled
12=Relay #1 toggled; Relay #2 timed open
21=Relay #1 timed open; Relay #2 toggled
The yellow indicator will flash quickly while the 918 searches its
memory for available space and duplicate entries. The green
indicator will light when the new code is stored.
If the new entry code chosen is already being used for another entry
code, the red indicator will light. A new unique code needs to be
entered.
Note: Leading zeros (zeros before the code number, i.e.0001) do not need to
be entered when programming a new code. The 918 will internally add any
zeros to fill digits determined by the entry code length setting. Leading zeros
will have to be entered by the user when entering their code to gain access.
Erasing a Single Entry Code
Press: 0 2 # Code # Code #
Code=The entry code to delete
The yellow indicator will flash quickly while the 918 searches its
memory for the code to erase. The green indicator will light when
the code is erased.
Erasing All Entry Codes
WARNING: PERFORMING THIS COMMAND WILL REMOVE
ALL ENTRY CODES FROM THE MEMORY
Press: 9 7 # 0 0 0 0 0 0 # 0 0 0 0 0 0 #
Note: The green indicator will light while the memory is being erased. This
may take up to 15 seconds.
Changing the 6-Digit Master Programming Code
Press: 9 8 # Master Code # Master Code #
Master Code=The new 6-digit Master Programming Code
New master code: ____________
PROGRAMMING OPTIONS
There are several 918 EntryCheck™ programming options. For
most installations, the factory set default options are sufficient.
The keypad must be in Programming Mode to make these
changes.
Programming the 918 To Hold the Output
SDC’s EntryCheck™ products have a programmable “Toggle
Mode” available for each relay and solid-state output. When an
output is programmed for Toggle Mode, the output alternates from
OFF to ON or from ON to OFF each time it is activated. When
output is toggled on, the green LED flashes until toggled off.
The rules for a toggle output are:
If the output is OFF, it will turn ON and stay on until the next
activation.
If the output is ON, it will turn OFF and stay off until the next
activation.
