Oxygen Transmitter • 12 Pioneer Operator’s Manual (PRELIMINARY)
Channel type screen
This screen indicates the channel type for Channel 1. The default setting for the channel
type (input) setting for the oxygen transmitter is
4-20 Remote .
• To accept the setting and continue the program, press the ENTER button.
The program displays the Relay 3 Assignment screen.
• To update the setting:
1. Use the UP/YES or DOWN/NO button to change the setting.
2. Press the ENTER button to accept the new setting and continue the program.
The program displays the Relay 3 Assignment screen.
Relay 3 assignment screen
This screen indicates the assignment of the alarm 3 relay for Channel 1. If you select
Alarm 3 , then the alarm 3 relay activates if Channel 1 goes into an alarm 3 condition.
If you select Fail Alarm , then the alarm 3 relay de-energizes if Channel 1 goes into a fail
condition.
NOTE: If you assign the alarm 3 relay as the channel’s fail relay, the status light and
buzzer still indicate visual and audible alarms for an alarm 3 condition.
• To accept the relay 3 assignment setting and continue the program, press the ENTER
button.
The program displays the Fail Setpoint screen.
• To update the relay 3 assignment setting:
1. Use the UP/YES or DOWN/NO button to change the setting.
2. Press the ENTER button to accept the new setting and continue the program.
The program displays the Fail Setpoint screen.
I N P U T : 4 - 2 0 R e m t e o
C h a n n e l 1
R e l a y 3 A s s i g n e d t o :
A l a r m 3
