Pioneer Operator’s Manual
CO Transmitter • 9
3.
Press the UP/YES, DOWN/NO, or ENTER button to continue.
The program asks if you want to setup Channel 1.
4.
To display or change settings for Channel 1, press the ENTER button (the program
displays the Channel Status screen.) To continue to Channel 2 settings, press the
UP/YES button. To go to Channel 4 settings, press the DOWN/NO button.
NOTE:
The screens illustrated in this section are examples and describe the Channel
Setup program for Channel 1.
Channel status screen
This screen indicates the status of Channel 1. For installed channels the default setting is
ACTIVE/ONLINE
. For empty channels, the default setting is
NO SENSOR/AMP
. The
third setting,
SILENCED/OFFLINE
, displays the gas reading as XXXX; and the buzzer,
status lights, and relays are disabled for the channel.
•
To accept the channel status setting and continue the program, press the ENTER
button.
The program displays the Fullscale Reading, Unit of Measure, and Target Gas screen.
•
To update the channel status setting:
1.
Use the UP/YES and DOWN/NO buttons to change the setting.
2.
Press the ENTER button to accept the new setting and continue the program.
The program displays the Fullscale Reading, Unit of Measure, and Target Gas screen.
NOTE:
If you select a channel status of
NO SENSOR/AMP
, the program continues with
the next channel.
Fullscale reading, unit of measure, and target gas screen
This screen indicates the fullscale reading, unit of measure, and target gas for Channel 1.
The default settings for the CO channel are
300
(fullscale reading),
PPM
(unit of measure),
and
CO
(target gas).
E N T E R
S e t
p
u
-
C h a n n e l
1
u
t -
E S C A
E
t
x i
P
U P / D
C
a n g e
C
N
N o w
S e
E
p
h
h a n n e l
C h a n n e l
1
A C T I V E / O
L I N E
N
0 0
P P M
C O
3
