Pioneer Operator’s Manual (PRELIMINARY)
Combustible Gas Transmitter • 23
8.
Reconnect the wiring from the Pioneer to the interconnect terminal strip as shown in
Table 4 and Figure 3, Wiring the Combustible Gas Transmitter to the Pioneer Gas
Monitor.
9.
Reconnect the detector leads to the interconnect terminal strip as shown in Table 5 and
Figure 3, Wiring the Combustible Gas Transmitter to the Pioneer Gas Monitor.
10. Place the Pioneer’s power switch in the ON position.
CAUTION:
Allow the detector to warm up for 15 minutes before you continue with the next step.
11. Calibrate the combustible gas transmitter as described in the Calibration section of
this insert.
Table 4: Reconnecting the Combustible Gas Amplifier to the Pioneer Gas Monitor
Amplifier
Interconnect Terminal Strip
Pioneer Analyzer Card
GND
Gnd (Terminal 7)
4-20
4-20 (Terminal 5)
24V
24 V (Terminal 6)
Table 5: Reconnecting the Combustible Gas Detector to the Amplifier
Detector Lead
Amplifier
Interconnect Terminal Strip
Red
SENSOR RED
White
SENSOR WHT
Green
SENSOR GRN
Black
SENSOR BLK
