CO Transmitter • 12
Pioneer Operator’s Manual
•
To update the alarm 2 setpoint:
1.
Use the UP/YES and DOWN/NO buttons to change the setpoint.
2.
Press the ENTER button two times to accept the new setting and continue the
program.
The program displays the Alarm 3 Setpoint screen.
•
To update the alarm type setting:
1.
Press the ENTER button to select the alarm type setting. (The setting flashes when
it is selected.)
2.
Use the UP/YES or DOWN/NO button to change the setting.
3.
Press the ENTER button to accept the new setting and continue the program.
The program displays the Alarm 3 Setpoint screen.
Alarm 3 setpoint screen
This screen indicates the setpoint and alarm type for Alarm 3. The default setting for the
alarm 3 setpoint for the CO channel is
100
. The default setting for the alarm type is
RISE
.
•
To accept the settings and continue the program, press the ENTER button two times.
The program begins channel setup for Channel 2.
•
To update the alarm 3 setpoint:
1.
Use the UP/YES and DOWN/NO buttons to change the setpoint.
2.
Press the ENTER button two times to accept the new setting and continue the
program.
The program begins channel setup for Channel 2.
•
To update the alarm type setting:
1.
Press the ENTER button to select the alarm type setting. (The setting flashes when
it is selected.)
2.
Use the UP/YES or DOWN/NO button to change the setting.
3.
Press the ENTER button to accept the new setting and continue the program.
The program begins channel setup for Channel 2.
NOTE:
To exit the Channel Setup program, press the ESCAPE button. The Channel
Setup Exit screen displays.
