Pioneer Operator’s Manual CO Transmitter • 11
• To update the fail setpoint setting:
1. Use the UP/YES and DOWN/NO buttons to change the fail setpoint setting.
2. Press the ENTER button two times to accept the new setting and continue the
program.
The program displays the Alarm 1 Setpoint screen.
• To update the alarm type setting:
1. Press the ENTER button to select the alarm type setting. (The setting flashes when
it is selected.)
2. Use the UP/YES or DOWN/NO button to change the setting.
3. Press the ENTER button to accept the new setting and continue the program.
The program displays the Alarm 1 Setpoint screen.
Alarm 1 setpoint screen
This screen indicates the setpoint and alarm type for Alarm 1. The default setting for the
alarm 1 setpoint for the CO channel is
25 . The default setting for the alarm type is RISE .
• To accept the settings and continue the program, press the ENTER button two times.
The program displays the Alarm 2 Setpoint screen.
• To update the alarm 1 setpoint:
1. Use the UP/YES and DOWN/NO buttons to change the setpoint.
2. Press the ENTER button two times to accept the new setting and continue the
program.
The program displays the Alarm 2 Setpoint screen.
• To update the alarm type setting:
1. Press the ENTER button to select the alarm type setting. (The setting flashes when
it is selected.)
2. Use the UP/YES or DOWN/NO button to change the setting.
3. Press the ENTER button to accept the new setting and continue the program.
The program displays the Alarm 2 Setpoint screen.
Alarm 2 setpoint screen
This screen indicates the setpoint and alarm type for Alarm 2. The default setting for the
alarm 2 setpoint for the CO channel is
50 . The default setting for the alarm type is RISE .
• To accept the settings and continue the program, press the ENTER button two times.
The program displays the Alarm 3 Setpoint screen.
C h a n n e l 1 A l a r m
2 5 P P M C O
1
R I S E
C h a n n e l 1 A l a r m
5 0 P P M C O
2
R I S E
