Pioneer Operator’s Manual (PRELIMINARY)
Combustible Gas Transmitter • 11
Channel status screen
This screen indicates the status of Channel 1. For installed channels the default setting is
ACTIVE/ONLINE
. For empty channels, the default setting is
NO SENSOR/AMP
. The
third setting,
SILENCED/OFFLINE
, displays the gas reading as XXXX; and the buzzer,
status lights, and relays are disabled for the channel.
•
To accept the channel status setting and continue the program, press the ENTER
button.
The program displays the Fullscale Reading, Unit of Measure, and Target Gas screen.
•
To update the channel status setting:
1.
Use the UP/YES and DOWN/NO buttons to change the setting.
2.
Press the ENTER button to accept the new setting and continue the program.
The program displays the Fullscale Reading, Unit of Measure, and Target Gas screen.
NOTE:
If you select a channel status of
NO SENSOR/AMP
, the program continues with
the next channel.
Fullscale reading, unit of measure, and target gas screen
This screen indicates the fullscale reading, unit of measure, and target gas for Channel 1.
The default settings for the combustible gas channel are
100
(fullscale reading),
%LEL
(unit of measure), and
COMB
(target gas).
•
To accept the settings and continue the program, press the ENTER button three times.
The program displays the Channel Type and Measuring Options screen.
•
To update the target gas, unit of measure, and/or fullscale reading setting:
1.
Use the ENTER and ESCAPE buttons to select the setting you want to change.
(The setting flashes when it is selected.)
2.
Use the UP/YES and DOWN/NO buttons to change the setting.
3.
Press the ENTER button until the program displays the Channel Type and
Measuring Options screen.
NOTE:
If you update the target gas, turn the Pioneer’s power switch OFF and then ON
again after you return to normal operation.
C h a n n e l
1
A C T I V E / O
L I N E
N
1 0 0
% L E L
C O M B
