D50 & D60 HEADER/ADAPTER
Form 169009 48 Model Year - 2009
r. If quick disconnects are installed, proceed as
follows:
1. Check connectors and clean if required.
2. Push hose connector onto mating
receptacle until collar on receptacle snaps
into lock position.
NOTE
Ensure hoses are clear of driveline and
adjacent structure.
s. Attach electrical connector as follows:
1. Remove cover on receptacle.
2. Align lugs on connector with slots in
receptacle, push connector onto receptacle
and turn collar on connector to lock it in
place.
3. Attach cover to mating cover on combine
wiring harness.
t. Raise and lower header and reel a few times to
allow trapped air to pass back to the reservoir.
NOTE
It is not necessary to bleed the system by
loosening fittings.
u. Check float and if the header is level. If
adjustments are required, refer to Section 7.3.5
Header Float, and Section 7.3.6 Header
Levelling.
ELECTRICAL
