The angle between the label and the
terminal is too high.
Change the angle between the bar code
and the terminal.
The distance is too far or too close.
Change the distance between the bar
code and the terminal.
The bar code is larger than the laser
beam.
Try moving the terminal a bit further away
from the bar code.
The read window is dirty.
Clean the read window of the terminal.
The read window is scratched.
The terminal needs service.
The type of the bar code label is not
enabled.
Enable the bar code symbology in the
application program.
When the terminal is placed in the cradle
(model SV or TC), the main battery is not
charged.
Check cradle type (model SV or TC)
The cradle needs a rechargeable battery
pack to charge. When a battery holder for
dry cell batteries Is used, the charger
does not work at all.
There is no contact between the terminal
and the cradle. Try again to place the
terminal properly, or clean the contacts.
Replace the battery pack and try again.
Terminal is still not charged. Red LED
indicator on terminal is turned on
The charger for the terminal is probably
defect. Take the battery pack out of the
terminal and charge it in the battery pack
charger (model TC). The cradle will need
service, but can still operate for a while.
?
?
?
?
?
?
?
When a rechargeable battery pack is placed
in the cradle (model TC), the main battery is
not charged.
Green LED indicator is not turned on not
flashing.
Check cradle type (TC)
The cradle needs a rechargeable battery
pack to charge. When a battery holder for
dry cell batteries is used, charger does not
work at all.
The battery pack in the terminal is not
empty enough. The battery voltage has to
be lower than 2.6 V.
The battery voltage reaches 4 V. The voltage
for charging should be between 2 - 4 V.
If the battery temperature reaches 45 o C,
the charger will stop charging immediately.
The cradle is waiting for the proper
temperature (0-40
o C) and will then
continue.
Green LED indicator keeps flashing.
The battery is too cold or too warm.
The cradle is waiting for the proper
temperature (0-40
o C) and will then
continue.
The rechargeable battery pack is still not
charged. Red LED indicator keeps on.
The charger for the battery pack is
probably defect.
Put the battery pack in the terminal and
charge it in the terminal charger.
The cradle will need service, but can still
operate for a while.
Backupbattery is empty.
Indicator in the display of the terminal is on:
Replace the Lithium CR2032 battery with a
new one.
?
?
?
?
7.3 BATTERY CHARGING
PROBLEMS
