6.1.5 Environmental specifications
Temperature -10 - +40 oC in operation
-20 - +60 oC in storage
Humidity 20 - 80 % in operation
(non condensing) 20 - 90 % in storage
Shock: drop: 1.5 m drop onto concrete surface
Shock: vibration: 10 - 50 Hz with 1G for 30 min,
cycle for X,Y,Z.
Ambient light rejection fluorescent 3.000 lux max.
direct sun 50.000 lux max.
Emission According to EN50081, part 1
Immunity According to EN50082, part 1
Protection against
dust and moisture
According to IEC529, IP 42
Safety, Laser class According to IEC825,
Class I laserproduct
6.1.6 Supported symbologies
Chinese Post 2of5
Codabar incl. ABC and CX
Code 39
Code 93
Code 128
EAN-8 incl. +2,+5
EAN-13 incl. +2,+5
IATA
Industrial 2of5
Interleaved 2of5
Italian Pharmaceutical
Laetus
Matrix 2of5
MSI/Plessey
UK/Plessey
S-Code
Telepen
UPC-A incl. +2,+5
UPC-E incl. +2,+5
6.2.1 Cradle models
model T: use for communication
model SV: use for communication / charging
battery in terminal
model TC: use for communication / charging
battery in terminal / charging battery in spare slot
6.2.2 Electrical specifications
Battery charging time when battery in terminal:
(transceiver/charger) 4 hours extra charge with
70% nominal capacity
when battery in spare
battery slot: 1 hour full charge
6.2.3 Functionality
Interfaces supported RS232
RS485
Serial communication RS232 Baudrate:
1200 - 38400
RS485 Baudrate:
1200 - 38400
Transmission modes Half duplex RS232
Half duplex RS485
Parity Odd, Even, None
6.2.4 Environmental specifications
Temperature 0 - +40 oC in operation
-20 - +70 oC in storage
Humidity 30 - 85 % in operation
(non condensing) 30 - 90 % in storage
Shock: vibration: 10 - 50 Hz with 1G for 30 min,
cycle for X,Y,Z.
Emission According to EN50081, part 1
Immunity According to EN50082, part 1
6.2.5 Physical specifications
Dimensions (l x w x d) 228 x 116 x 97 mm (desk top)
Case material ABS
Weight (excl. cables)
model SV: 475 g
model T: 500 g
model TC : 525 g
Standard connector RS232 - D Sub 9P Female
RS485 - 6 pins modular plug
6.2 SPECIFICATIONS CRADLE
