U
SER
’
S MANUAL
PHL 1700
LASER TERMINAL
/ IRU 1700
CRADLE
18
6.1.1 Electrical specifications
Main battery rechargeable pack: Ni-MH
dry cell: Alkaline penlite
optional: other 2 x AA-size
penlite
Main battery Ni-MH: When making every 5
operating time seonds 1 scan with 1 sec
laserbeam on and 0.2 sec.
green LED on and 0.2 sec.
buzzer on, operating time is:
approx. 34 hours
Alkaline: When making every 5
seonds 1 scan with 1 sec
laserbeam on and 0.2 sec.
green LED on and 0.2 sec.
buzzer on, operating time is:
approx. 67 hours
Different operation conditions
affect the operating time
Use of other penlite batteries
affect the operating time
Backup battery Lithium (CR2032)
Backup battery If fully charged:
operating time 4 months backup time
Battery Low voltage indicated on the
management terminal display.
When battery is low the terminal
switches off automatically.
Charging method Rechargeable Ni-MH pack in
terminal via cradle
Replacement Ni-MH pack in
cradle
6.1.2 Optical specifications
Light source 650 nm visible laser diode
Scan rate 100 scans/sec
Decode rate 100 decodes/sec
Reading width 60 mm at 30 mm
98 mm at 100 mm
Resolution at PCS 0,9 0.15 mm (6mil)
Depth of field 0 - 140 mm (at PCS 0.9, res. 0.25)
6.1.3 Physical specifications
Dimensions (l x w x d) 172 x 62 x 44 mm
Case material ABS
Weight body (excl. battery): 180 g
Direct cable (optional) RS232 - DB9 female
6.1.4 Functionality
Memory ROM: 32 kB
FlashROM (for O/S and
program): 256 kB
fast RAM: 2kB
battery backed up S-RAM
(for data): 1 or 2 MB
Microprocessor 16-bit
Real time clock Quartz RTC, time and date
programmable, leap year
handling,
(accuracy + 60 sec./month)
Display 96x48 Pixels
graphic LCD with backlight
Character fonts:
4/8 lines x 16 characters
Keyboard 27 keys total
(26 keys user definable)
8 Function keys
Alpha/Numeric mode
Trigger mode Manual
Programming Functionality is provided by user
application. The application may
be downloaded from PC via
cable, com port or IrDA.
Interfaces supported RS232 by direct cable
RS232 by cradle
IrDA on terminal
Transmission speed RS232 direct cable:
2400 - 115200 baud
RS232 cradle:
2400 - 38400 baud
IrDA terminal:
2400 - 115200 baud
SPECIFICATIONS
6
6.1 SPECIFICATIONS TERMINAL
