wrs5200 hydraulic roller screed • operaTion manual — rev. #1 (10/22/10) — page 33
rOller ScreeD aSSeMblY
Task 2: middle Truss sections (reference figure 17)
1. Locate the 8 ft. (2.4 m) right-side section of truss d.
This truss section can be identified by the RM8 marking
on the top pipe.
2. Next locate the other 8 ft. (2.4 m) left-side section of
truss e. This truss section can be identified by the LM8
marking on the top pipe.
3. Reference detail B, and join truss sections d and e
together. Use the 1/2-13X1-1/2 HHCS screws (12)
when assembling these two truss sections along
with 1/2-inch flat washers (24) and 1/2-inch nyloc nut
(12).
Task 3: middle Bracket)
Locate middle bracket P/N 16653. Place middle bracket
between 3 ft. truss section ( c) and the 8 ft. truss section
( d) as outlined in Figure 17.
4. Use the 1/2-13X1-3/4 HHCS screws (12) when joining
truss sections c, d and e (with middle bracket) along
with 1/2-inch flat washers (24) and 1/2-inch nyloc nut
(12).
Task 4: Bearing installation
If the strike tube bearing has not been installed onto the
middle bracket perform the following:
1. Mount strike tube bearing onto middle bracket.
2. Secure strike tube bearing with 7/16-14x2 HHSC
screws (2) and 7/16 nyloc nuts (2). Torque bearing
support nuts to 75 ft.-lbs. (102 N.m).
3. Insert splined shaft into middle mounting bracket as
shown in Figure 17.
4. Tighten bearing set secrews to secure splined shaft.
