wrs5200 hydraulic roller screed • operaTion manual — rev. #1 (10/22/10) — page 27
The definitions below describe the controls and functions
of the Power Unit (Figure 12).
1.
liftng support hook — Insert lifting rod (item 4)into
support hook when lifting of the power unit is required.
This feature is on older units only.
2. halogen lights — Power unit is equipped with two 50
watt halogen lights. Lights can be used when working
in dark areas or at night.
3. lifting straps — When liting of the power unit is
required, secure these straps to the power unit frame.
Straps are used on older units only. Make sure lifting
device has adequate lifting capacity for lifting the
power unit.
4. lifting rod — Insert this rod into the lifting hook
(bottom of frame item 1) when lifting of the power unit
is required.
5. muffler — Required to reduce noise and emissions.
NEVER touch muffler while it is hot.
6. radiator/cap — Fill with recommended coolant.
NEVER remove radiator cap while engine is hot. Allow
a sufficient amount of time for radiator to cool before
removing cap.
7. emergency stop Button — In the event of an
emergency press this button. do noT use this button
as a method of shutting down the unit. Pull button
outward when re-starting.
8. sterring handles — Use these handles (2) to steer
and position the power unit.
9. hydraulic motor support Bracket — Place strike
tube hydraulic motor into this bracket whenever the
drive tube requires maintenance or dis-assmbly. Insert
cotter-pin to keep motor from falling.
10. overflow Bottle — Fill with recommended type
coolant. Always maintain proper coolant level.
11. Battery — Provides +12VDC for power unit electronics.
Replace with recommended type battery only.
12. control lever — 3-position lever, pressure washer,
neutral and screed operation
13. serial number plate — When ordering parts, use
information on this plate to identify model and type
of unit.
pOWer unit cOMpOnentS
14. control Box receptacle — Insert the control box
power cable into this receptacle
15. fuel Tank — Fill with clean fresh diesel fuel. Fuel tank
capacity is 5 gallons (19 liters) of diesel fuel.
16. lifting Bail — Attach a chain, rope or strap to this
lifting bail whenever lifting of the power unit is required.
This bail is installed only on newer units. Make sure
lifting device has adequate lifting capacity for lifting
the power unit.
17. engine — The unit uses a 26.5 HP Vanguard
diesel engine. Reference engine owners manual or
maintenance section in this manual for engine care
and service.
18. Tires — This unit employes semi-pnuematic tires. The
power unit should never be towed on a highway.
Always replace tires with original size type tire.Tires
are designed to be puncture proof
19. fuel gauge — Displays the amount of diesel fuel in
the fuel tank.
20. hydraulic fluid gauge — Displays the amount of
hydraulic fluid in the hydraulic tank. Also the gauge will
display the temperature of the hydraulic fluid.
21. hydraulic reservoir Tank/cap — This Remove this
cap to add hydraulic fluid. Fill with AW MV ISO 46
type hydraulic fluid. Reservoir capacity is 5 gallons (19
liters) of diesel fuel.
22. Quick-disconnect coupling (output) — Connect
hydraulic motor drive line to this output port. Make
sure to cover coupling with dust cap to prevent dirt and
debris from contamining hydraulic fluid system.
23. Quick-disconnect coupling (return) — Connect
hydraulic motor return line to this input port. Make
sure to cover coupling with dust cap to prevent dirt and
debris from contamining hydraulic fluid system.
