wrs5200 hydraulic roller screed • operaTion manual — rev. #1 (10/22/10) — page 17
DiMenSiOnS (rOller ScreeD)
Table 2. roller screed dimensions
reference
letter
dimension ft. (meters)
A 5 (1.5)
B 5 (1.5)
C
14 (4.3), 16 (4.9), 18 (5.5), 22 (6.7), 26 (7.9), 28 (8.5),
30 (9.1), 32 (9.8), 36 (11), 40 (12.2), 44 (13.4),
48 (14.6) and 52 (15.8)
D TBD
E TBD
Figure 6. Roller Screed Dimensions
