page 16 — wrs5200 hydraulic roller screed • operaTion manual — rev. #0 (10/22/10)
Table 1. roller screed specifications
Available Lengths ft. (m)
14 (4.25), 18 (5.4), 22 (6.7), 26 (7.9), 28 (8.5), 32 (9.7),
36 (10.9), 40 (12.1) and 52 (15.8)
Working widths ft. (m) 1.2 (3.6) to 50 (15.2)
Strike Tube Speed 450 RPM Maximum
Drive Tube Speed 150 RPM Maximum
Weight (Max Length) 1,500 lbs. (680 kg)
Sound Level at 23 ft./7 meters 103 dB(A)
power unit specifications w
Hydraulic Operating Pressure 2,000 psi (6.90 kPA)
Hydrostatic Flow rate 17 gpm (64 lpm)
Hydraulic Oil Type AW MV ISO 46
Hydraulic Oil Tank Capacity 5 gals. (19 liters)
Hydraulic Pump Type Hydrostatic — Eaton
Hydraulic Pressure Washer lbs. — Option 55 lbs. (25 kg)
Hydraulic Pressure Washer Flow Rate — Option 6 gpm (23 lpm) @ 2000 psi (41.37 kPA)
Fuel Tank Capacity 5 gals. (19 liters)
Tires (4) Semi-Pnuematic 3X12
Lighting (2) 50 Watt Halogen
Battery 12V Group U1 Wet Cell
Weight 677 lbs. (307 kg)
engine specifications
Engine
Briggs-Stratton, Vanguard Liquid Cooled
Model DM950
Number of Cylinders 3
Bore X Stroke 2.68 (68 mm) X 3.07 (78 mm)
Displacement 58.1 cu. in (953 cc)
Horsepower 26.5 HP @3600 rpm
Oil Type 5W-30, CF, and CF-4
Oil Capacity Without Filter 3.25 qts. (3.1 liters)
Oil Capacity With Filter 3.50 qts. (3.3 liter
Fuel Type Diesel Fuel
Starting Method Electric
SpecificatiOnS
