Introduction

Digital Inputs
-

The PositionServo has twelve digital inputs that are utilized by the drive for decision making in the User Program.
Example uses: travel limit switches, proximity sensors, push buttons and hand shaking with other devices.

-

Each input can be assigned an individual debounce time via MotionView. From the

Parameter Tree, select [IO].

Then select the [

Digital Input] folder. The debounce times will be displayed in the Parameter View Window.

Debounce times can be set between 0 and 1000 ms (1ms = 0.001 sec). Debounce times can also be set via
variables in the user program.

- The twelve inputs are separated into three groups: A, B and C. Each group has four inputs and share one

common: Acom, Bcom and Ccom respectfully. The inputs are labeled individually as

IN_A1 - IN_A4, IN_B1

- IN_B4 and IN_C1 - IN_C4.

-

In addition to monitoring each input individually, the status of all twelve inputs can be represented as one binary
number. Each input corresponds to 1 bit in the INPUTS system variable. Use the following format:

System

Variable

INPUTS

Bit #

11

10

9

8

7

6

5

4

3

2

1

0

Input

Name

C4

C3

C2

C1

B4

B3

B2

B1

A4

A3

A2

A1

-

Some inputs can be configured for additional predefined functionality such as Travel Limit switch, Enable input,
and Registration input. Configuration of these inputs is done from MotionView or through variables in the user
program. Input special functionality is summarized in the table below and in the following sections. Table 4
summarizes the special functions for the inputs.

Table 4: Input Functions

Input Name

Special Function

Input A1

Negative limit switch

Input A2

Positive limit switch

Input A3

Inhibit/Enable input

Input A4

N/A

Input B1

N/A

Input B2

N/A

Input B3

N/A

Input B4

N/A

Input C1

N/A

Input C2

N/A

Input C3

Registration sensor input

Input C4

N/A

The current status of the drive’s inputs is available to the programmer through dedicated System Flags or as
bits of the System Variable INPUTS.
