Reference – Lenze E94P PositionServo with MVOB User Manual
Page 120
118
L
PM94H201B_13xxxxxx_EN
Reference
Index Name
Type Format EPM Access Description
Units
NOTE: PIDs 283 - 309 are for REFERENCE ONLY. These variables are set through MotionView. Do NOT use directly.
283
PBUS_ADDR
W
Y
R/W Profibus address
284
PBUS_DOUT_SIZE
W
Y
R/W
Number of Profibus Data Out channels
Range: 0 - 12
285
PBUS_DIN_SIZE
W
Y
R/W
Number of Profibus Data In channels
Range: 0 - 12
286
PBUS_OUT_LINK1
W
Y
R/W Profibus Data Out, Channel link 1 PID map
287
PBUS_OUT_LINK2
W
Y
R/W Profibus Data Out, Channel link 2 PID map
288
PBUS_OUT_LINK3
W
Y
R/W Profibus Data Out, Channel link 3 PID map
289
PBUS_OUT_LINK4
W
Y
R/W Profibus Data Out, Channel link 4 PID map
290
PBUS_OUT_LINK5
W
Y
R/W Profibus Data Out, Channel link 5 PID map
291
PBUS_OUT_LINK6
W
Y
R/W Profibus Data Out, Channel link 6 PID map
292
PBUS_OUT_LINK7
W
Y
R/W Profibus Data Out, Channel link 7 PID map
293
PBUS_OUT_LINK8
W
Y
R/W Profibus Data Out, Channel link 8 PID map
294
PBUS_OUT_LINK9
W
Y
R/W Profibus Data Out, Channel link 9 PID map
295
PBUS_OUT_LINK10
W
Y
R/W Profibus Data Out, Channel link 10 PID map
296
PBUS_OUT_LINK11
W
Y
R/W Profibus Data Out, Channel link 11 PID map
297
PBUS_OUT_LINK12
W
Y
R/W Profibus Data Out, Channel link 12 PID map
298
PBUS_IN_LINK1
W
Y
R/W Profibus Data In, Channel link 1 PID map
299
PBUS_IN_LINK2
W
Y
R/W Profibus Data In, Channel link 2 PID map
300
PBUS_IN_LINK3
W
Y
R/W Profibus Data In, Channel link 3 PID map
301
PBUS_IN_LINK4
W
Y
R/W Profibus Data In, Channel link 4 PID map
302
PBUS_IN_LINK5
W
Y
R/W Profibus Data In, Channel link 5 PID map
303
PBUS_IN_LINK6
W
Y
R/W Profibus Data In, Channel link 6 PID map
304
PBUS_IN_LINK7
W
Y
R/W Profibus Data In, Channel link 7 PID map
305
PBUS_IN_LINK8
W
Y
R/W Profibus Data In, Channel link 8 PID map
306
PBUS_IN_LINK9
W
Y
R/W Profibus Data In, Channel link 9 PID map
307
PBUS_IN_LINK10
W
Y
R/W Profibus Data In, Channel link 10 PID map
308
PBUS_IN_LINK11
W
Y
R/W Profibus Data In, Channel link 11 PID map
309
PBUS_IN_LINK12
W
Y
R/W Profibus Data In, Channel link 12 PID map
310
PBUS_ACYC_MODE
W
Y
R/W
Profibus Acyclic Mode Type
Refer to Profibus Manual (P94PFB01)
NOTE: PIDs 311 - 406 are for REFERENCE ONLY. These variables are set through MotionView. Do NOT use directly
These variables are used by MotionView for non-volatile settings of CAN TPDO/RPDO.
311
VAR_RPDO_1_COM
Receive PDO
312
VAR_RPDO_2_COM
313
VAR_RPDO_3_COM
314
VAR_RPDO_4_COM
