Parameterisation 8200 vector/8200 motec
Menu structure
7
EDK9371BC DE/EN/FR 3.1 95
l
H1 Parametrierung 8200−9371BC_6L
Description Submenus Main menu Description
Display No. Display No.
5.15 Vector−Ctrl 7 Operation with the fieldbus function
module on FIF (DRIVECOM control)
Frequency setpoint via process data
channel
5.15.1 FIF managem Set up fieldbus communication
5.15.2 Freq setpt Frequency setpoint configuration
5.15.3 f limit/ramp Output frequency, acceleration time
and deceleration time configuration
5.15.4 Motor param Motor current control and motor
monitoring configuration
5.15.5 Motor ident Motor parameter identification
Sensorless torque control with speed limitation
5.16 Torque−Ctrl 0 Analog selection of torque setpoint
via analog input 1 (AIN1)
Speed limitation via maximum
frequency C0011
5.16.1 Torque setpt Torque setpoint configuration
5.16.2 f limit Speed limitation configuration
5.16.3 Motor param Motor current control and motor
monitoring configuration
5.16.4 Motor ident Motor parameter identification
5.17 Torque−Ctrl 1 Analog selection of torque setpoint
via parameter channel possible
(C0047)
Speed limitation via maximum
frequency C0011
5.17.1 Torque setpt Torque setpoint configuration
5.17.2 f limit Speed limitation configuration
5.17.3 Motor param Motor current control and motor
monitoring configuration
5.17.4 Motor ident Motor parameter identification
