Parameterisation 8200 vector/8200 motec
Menu structure
7
EDK9371BC DE/EN/FR 3.1 89
l
H1 Parametrierung 8200−9371BC_6L
Menu structure
For simple, user−friendly operation, the codes are clearly arranged in function−related
menus:
Main menu Submenus Description
No. Display No. Display
1 USER menu Codes defined in C0517
2 Code list All available codes
2.1 All All available codes listed in ascending
order
2.2 Para set 1 Codes in parameter set 1
2.3 Para set 2 Codes in parameter set 2
2.4 Para set 3 Codes in parameter set 3
2.5 Para set 4 Codes in parameter set 4
2.6 Para set FIF Codes in function module
(only for assembled function
modules, application I/O, Interbus,
Profibus−DP, Lecom−B, DeviceNet,
CANopen)
3 Remote para Remote parameterisation
Only active with the system bus
function module
(CAN)
4 Quick start Quick commissioning of standard
applications
4.1 Keypad quick Function control
Frequency setpoint via keypad
4.2 V/f quick Linear V/f characteristic control
Analog selection of frequency
setpoint via potentiometer and of
fixed setpoints (JOG) via terminal
possible
4.3 VectorCtrl qu Vector control
Analog selection of frequency
setpoint via potentiometer and of
fixed setpoints (JOG) via terminal
possible
