Parameterisation 8200 vector/8200 motec
Menu structure
7
EDK9371BC DE/EN/FR 3.1 105
l
H1 Parametrierung 8200−9371BC_6L
Description Submenus Main menu Description
Display No. Display No.
13 FIF−field bus Configuration for operation with
fieldbus function modules and
display of the contents of the process
data words
Only active with the fieldbus function
module
13.1 Identify Display of software version and type
of fieldbus function module
13.2 FIF managem FIF communication parameters
13.3 POW setup Process data from master to fieldbus
function module
13.4 PIW setup Process data from fieldbus function
module to master
13.5 Com.err setup Communication monitoring
СССССССССССССС
СССССССССССССС
You need to change to the code level to be able to display the contents of
the data words. The contents of the data words are displayed as decimal
values.
13.6 Monit PIW Display of process data from fieldbus
function module to master
13.7 Monit POW Display of process data from master
to fieldbus function module
13.8 Monit FIF−IN Display of process data from fieldbus
function module to controller
13.9 Monit FIF−OUT Display of process data from
controller to fieldbus function
module
14 Motor/Feedb. Motor data entry, speed feedback
configuration
14.1 Motor data Motor data
14.2 Feedback DFIN DFIN frequency input, encoder
15 Identify Identification
15.1 Drive Software version of controller
15.2 Keypad Software version of keypad
15.3 FIF module Software version and type of function
module
