Parameterisation 8200 vector/8200 motec
Menu structure
7
EDK9371BC DE/EN/FR 3.1 93
l
H1 Parametrierung 8200−9371BC_6L
Description Submenus Main menu Description
Display No. Display No.
5.9 OpenLoopV/f 5 Operation with the system bus (CAN)
function module on FIF
Frequency setpoint via process data
channel (CAN−IN1.W2)
5.9.1 CAN managem Set up system bus (CAN)
communication
5.9.2 Freq setpt Frequency setpoint configuration
5.9.3 f limit/ramp Output frequency, acceleration time
and deceleration time configuration
5.9.4 Motor param Motor current control and motor
monitoring configuration
5.10 OpenLoopV/f 7 Operation with the fieldbus function
module on FIF (DRIVECOM control)
Frequency setpoint via process data
channel
5.10.1 FIF managem Set up fieldbus communication
5.10.2 Freq setpt Frequency setpoint configuration
5.10.3 f limit/ramp Output frequency, acceleration time
and deceleration time configuration
5.10.4 Motor param Motor current control and motor
monitoring configuration
Speed control in the "Vector control" operating mode
5.11 Vector−Ctrl 0 Analog selection of frequency
setpoint via analog input 1 (AIN1)
5.11.1 Freq setpt Frequency setpoint configuration
5.11.2 f limit/ramp Output frequency, acceleration time
and deceleration time configuration
5.11.3 Motor param Motor current control and motor
monitoring configuration
5.11.4 Motor ident Motor parameter identification
