Parameterisation 8200 vector/8200 motec
Menu structure
EDK9371BC DE/EN/FR 3.1
104
l
H1 Parametrierung 8200−9371BC_6L
Description
Submenus
Main menu
Description
Display
No.
Display
No.
12
FIF−systembus
Configuration for operation with the
system bus (CAN) function module
and display of the contents of the
CAN objects
Only active with the system bus
(CAN) function module
12.1
CAN managem
CAN communication parameters
12.2
Cfg CAN−IN1
CAN object 1
12.3
Cfg CAN−OUT1
12.4
Cfg CAN−IN2
CAN object 2
12.5
Cfg CAN−OUT2
12.6
Status words
Status word display
12.7
CAN diagn
CAN diagnostics
Only active for standard devices from software version 2.2:
You need to change to the code level to be able to display the contents of
the data words. The contents of the data words are displayed as
hexadecimal values.
12.8
Mon IN1 W1−2
Contents of the 4 input words/output
words of CAN object 1
Analog words: 5DC0h
º 480 Hz
Digital words: Hexadecimal
representation of the individual bits
12.9
Mon IN1 W3−4
12.10
Mon OUT1 W1−2
12.11
Mon OUT1 W3−4
12.12
Mon IN2 W1−2
Contents of the 4 input words/output
words of CAN object 2
Analog words: 5DC0h
º 480 Hz
Digital words: Hexadecimal
representation of the individual bits
12.13
Mon IN2 W3−4
12.14
Mon OUT2 W1−2
12.15
Mon OUT2 W3−4
