8 Parameterisation 9300 series
Change and save parameters
EDK9371BC DE/EN/FR 3.1 106
l
Parametrierung 9300−9371BCme93
8 Parameterisation 9300 series
Change and save parameters
All parameters for controller setting or monitoring are saved in codes. The codes are
numbered and labelled in the documentation with a "C". Some codes store the parameters
in numbered subcodes", so that a clear parameter setting is ensured (e. g.: C0517 User
menu).
The codes are described in detail in the system manual of the drive controller.
)
Note!
Your settings have an effect on the current parameters in the main memory.
You must save your settings in a parameter set so that they are not lost when
the mains are connected.
If you only need one parameter set, save your settings as parameter set 1, since
parameter set 1 is loaded automatically after mains connection.
Step Key sequence Action
1. Select the menu z y Z Y Use the arrow keys to select the desired
menu
2. Change to the code level Z Display of the first code in the menu
3. Select code or subcode y z Display of the current parameter value
4. Change to the parameter level V
5. When SHPRG is displayed,
inhibit the controller S 1) The drive coasts
6. Change parameter
A Z Y Move cursor below the digit to be
changed
B y z Change of digit
T y
T z
Quick change of digit
7. Accept the changed parameter
Display of SHPRG or SHPRG
p T V Confirm change to accept the parameter
Display "OK"
Display p − The parameter has been accepted
immediately
8. Enable the controller, if
required U 1) The drive runs again
