Parameterisation 8200 vector/8200 motec
Transmit parameter sets
7
EDK9371BC DE/EN/FR 3.1 79
l
H1 Parametrierung 8200−9371BC_6L
Transmit parameter sets
The keypad enables you to copy parameter settings from one standard device to another.
Use "Param managm" in menu 7 for this purpose:
Copy parameter sets from the standard device to the keypad
Step Key sequence Action
1. Connect the keypad to
standard device 1
2. Inhibit the controller S The drive coasts
3. Select the "Load/Store"
submenu 7.1 in the "Param
managm" menu 7 z y Z Y Change to the "Load/Store" submenu
using the arrow keys
4. Change to the code level Z "Param managm" is displayed in C0002
5. Change to the parameter level V "0" and "READY" are displayed
6. Select the correct copy function The settings stored in the keypad are
overwritten.
l Copy all available parameter sets (PAR1 ... PAR4, FPAR1 if applicable) into the keypad:
– Standard device with
function module
Application I/O,
INTERBUS,
PROFIBUS−DP, LECOM−B,
DeviceNet, CANopen
z Copy PAR1 ... PAR4 and FPAR1:
ð
Set "80" "F1&PAR1−4−>Key"
– Standard device with all
other function modules
Copy PAR1 ... PAR4:
ð
Set "20" "PAR1−4−>Keypad"
l Only copy the module−specific parameter set FPAR1 to the keypad:
– Only possible for
standard devices with
function module
INTERBUS,
PROFIBUS−DP, LECOM−B,
DeviceNet, CANopen:
z Copy FPAR1:
ð Set "50" "FPAR1−>Keypad"
