Parameterisation 9300 series
Transmit parameter sets
EDK9371BC DE/EN/FR 3.1
111
l
Parametrierung 9300−9371BCme93
Step
Key sequence
Action
1.
Connect the keypad to
standard device 1
2.
Inhibit controller
Terminal X5/28 = LOW
The drive coasts.
3.
Select C0003 in the
"Load/Store" menu
z y Z Y
Select code C0003 "PAR SAVE" in the
"Load/Store" menu using the arrow keys.
4.
Change to the parameter level
V
Display "0" and "READY"
5.
Copy all parameter set into the
keypad
The settings saved in the keypad are
overwritten.
z
Set "11" "Save extern"
6.
Start copying
T V
The "RDY" status display goes off. As
parameter value "BUSY" is displayed.
If "BUSY" goes off after approx. one
minute, all parameter sets were copied
into the keypad. The "RDY" status display
is lit.
7.
Change to the code level
A
V
Display of the operating level
B
V
Display C0003 and "PAR SAVE"
8.
Enable controller
Terminal X5/28 = HIGH
9.
Remove keypad from standard
device 1
Copying parameter sets fom keypad into the standard device
Step
Key sequence
Action
1.
Connect the keypad to
standard device 2
2.
Inhibit controller
Terminal X5/28 = LOW
The "IMP" status display is it.
The drive coasts
3.
Pull the plugs X5 and X6
All control terminals have the defined
"LOW" status.
4.
Select C0002 in the
"Load/Store" menu
z y Z Y
Select code C0002 "PAR LOAD" in the
"Load/Store" menu using the arrow keys.
5.
Change to the parameter level
V
The active parameter set is shown, e. g.
display "0" and "Load Default"
