9 Technical data
112
9.13 Probes for the operating medium air
Note: because of the high response accuracy, the use of thermowells (immersion sleeves) is not admissible.
Current type designation
Probe type
Temperature range
Nom. length mm
Process connection
RTD temperature probe data sheet 902006
902006/65-228-1003-1-15-500-668/922
1 × Pt100
-170 to +700 °C
500
902006/65-228-1003-1-15-710-668/922
710
902006/65-228-1003-1-15-1000-668/922
1000
902006/55-228-1003-1-15-500-254/922
1 × Pt100
-170 to +700 °C
500
902006/55-228-1003-1-15-710-254/922
710
902006/55-228-1003-1-15-1000-254/922
1000
902006/65-228-2003-1-15-500-668/922
2 × Pt100
-170 to +700 °C
500
Stop flange
displaceable
902006/65-228-2003-1-15-710-668/922
710
902006/65-228-2003-1-15-1000-668/922
1000
902006/55-228-2003-1-15-500-254/922
2 × Pt100
-170 to +700 °C
500
Displaceable
screw connection G1/2
902006/55-228-2003-1-15-710-254/922
710
902006/55-228-2003-1-15-1000-254/922
1000
Thermocouples data sheet 901006
901006/65-547-2043-15-500-668/922
2 × NiCr-Ni, type "K"
-35 to +800 °C
500
Stop flange
displaceable
901006/65-547-2043-15-710-668/922
710
901006/65-547-2043-15-1000-668/922
1000
901006/65-546-2042-15-500-668/922
2 × Fe-CuNi, type "L"
-35 to +700 °C
500
901006/65-546-2042-15-710-668/922
710
901006/65-546-2042-15-1000-668/922
1000
901006/66-550-2043-6-500-668/922
2 × NiCr-Ni, type "K"
-35 to +1000 °C
500
901006/66-550-2043-6-355-668/922
355
901006/66-550-2043-6-250-668/922
250
901006/66-880-1044-6-250-668/922
1 × PT10Rh-PT, type "S"
0 to 1300 °C
250
901006/66-880-1044-6-355-668/922
355
901006/66-880-1044-6-500-668/922
500
901006/66-880-2044-6-250-668/922
2 × PT10Rh-PT, type "S"
0 to 1300 °C
250
Stop flange
displaceable
901006/66-880-2044-6-355-668/922
355
901006/66-880-2044-6-500-668/922
500
