2 status indication mpg, Led meaning Page 31
Page 31

tina83e1-a (2014-02)
31
4.2
Status Indication MPG
DIA
ADJ
CAL
HV-ST
ST
E
C
A
0 2
4
6
8
Supply voltage
Error
High voltage
cold cathode
For factory
setting only
Calibration
value
LED Meaning
off off
No
supply
voltage
lit solid
green
off
Supply voltage = ok, Pirani active, no
high voltage in the measuring chamber
lit solid
green
blinking
green
Supply voltage = ok,
pressure in the cold cathode range, cold
cathode has not ignited
lit solid
green
lit solid
green
Cold cathode has ignited.
lit solid red
off
Measurement system error
blinking
red
off EEPROM
error
Troubleshooting (
→ 50).
