INFICON Gemini ATM to Ultra-High Vacuum Gauge User Manual
Page 25
tina83e1-a (2014-02)
25
For potentially contaminating applications and to protect the
measurement system against contamination, installation of the
optional seal with centering ring and filter is recommended
(Options
→ 53).
Remove the protective lid and connect the product to the
vacuum system.
or
Protective lid
Seal with centering
ring and filter
Clamp
Seal with centering ring
Keep the protective lid.
