5 replacing the sensor – INFICON BCG450 ATM to Ultra-High Vacuum Triple Gauge User Manual
Page 49
tina40e1-b (2011-04)
49
Replacement is necessary, when
• the sensor is severely contaminated
• the sensor is mechanically deformed
• the sensor is faulty, e.g. filament of hot cathode broken (→ 47)
• the sensor is faulty, e.g. Pirani element broken (→ 47)
• Allen key, AF 2.5
• Spare sensor (→ 50)
Deinstall the gauge (
→ 43).
Deinstall the electronics unit from the faulty sensor and mount it to the new
sensor (
→ 15).
6.5 Replacing the Sensor
Required tools / material
Procedure
