Wiring diagram connecting the power supply – INFICON BCG450 ATM to Ultra-High Vacuum Triple Gauge User Manual
Page 24

24
tina40e1-b (2011-04)
13
14
8
15
5
2
3
5
4
6
7
8
N
PE
L
DC
AC
GND
+24 V
PE
BCG450
D-Sub,
15-pin
RS232C
D-Sub, 9-pin
Mains
90 ... 250 VAC
50 ... 60 Hz
Connect the power supply to the the gauge and lock the connector with the
screws.
Connect the RS232C line to the instrument or control device and lock the
connector with the screws.
RS232C
Power
supply
Mains
BCG450
PC
Connect the power supply to the mains.
The gauge can now be operated via RS232C interface (
→ 33).
Wiring diagram
Connecting the power supply
