INFICON BCG450 ATM to Ultra-High Vacuum Triple Gauge User Manual

Page 20

background image

20

tina40e1-b (2011-04)

SP A
SP B

SP A

2)

SP B

2)

Degas

42 k

Ω

3
6
1
4
9

11

13

14

7

8

2

12

5

15

1.25 AT

24V

Degas

Ident.

10

-

-

-

1)

( )

+

-

Measuring

signal

-

8

9

1

15

D-Sub,15-pin,
female,
soldering side

Common (power GND 24V supply)

Ground (housing, vacuum connection)

Threshold values

Electrical connection

Pin 1

Relay switching function A, n.o. contact

2)

Pin 2

Measuring signal output

0 … +10.13 V

Pin 3

Threshold (setpoint) A

1)

0 … +10 V

Pin 4

Relay switching function A, com contact

2)

Pin 5

Supply common

0 V

Pin 6

Threshold (setpoint) B

1)

0 … +10 V

Pin 7

Degas on, active high

0 V/+24 V

Pin 8

Supply

+24 V

Pin 9

Relay switching function B, n.o. contact

2)

Pin 10

Gauge identification

Pin 11

Relay switching function B, com contact

2)

Pin 12

Measuring signal common

Pin 13

Do not connect

Pin 14

Do not connect

Pin 15

Do not connect

1)

Do not connect pin 3 and pin 6 for normal operation of the gauge. These
pins are reserved for adjustment of the setpoint potentiometers
(

→ 42).

2)

Relay assignement can be reprogrammed for atmosphere switching

function via serial interfaces (

→ 31 and [1] or [2]).

WARNING

Incorrect connection, incorrect polarity or inadmissible supply
voltages can damage the gauge.

Sensor cable connection
BCG450-SD, -SP
