INFICON Sensistor ILS500 Leak Detection System User Manual
Page 90

90
Technical Data
ninb63e1-f (1410)
Commands
The printer port can also be used to control the ILS500. The most commonly used
functions can be started/configured over the RS232 interface. Always use New Line
(0A,LF) as end character.
Command
Action
M<0A>
Starts a test cycle.
Q<0A>
Stop
N<0A>
Print request
K<0A>
Starts a calibration. If the function is busy, the ILS500 prints the
time remaining for the ongoing calibration in seconds. For
example, if two seconds remains the printout is as follows: WAIT
2 <0A>
S<0A>
Statistics (see table below)
RS<0A>
Reset statistics
R<09>
Factory Default<0A> Loads a recipe. For example
“R<09>Factory Default” loads the recipe Factory Default. When
the recipe is loaded the recipe name is echoed back. If a recipe
name isn’t in the ILS500 the answer from the ILS500 will be “Not
a recipe name!”
Statistics
Printed data
Explanation
REC:AP29
- recipe name.
Printed if recipes is activated
TOT:00031
- total
ACC:00009
- accepted
REJ:00022
- rejected
EVA:00001
- evacuation
VDE:00000
- vacuum decay
BLO:00006
- blockage test
FIL:00001
- gas filling
PRE:00000
- pressure decay
GAS:00014
- gas detector
