INFICON Sensistor ILS500 Leak Detection System User Manual
Page 25

Setup
25
ninb63e1-f (1410)
6.2.2
Connecting the Probe
1
Use the Probe Cable to connect the Probe to the ILS500.
Probe connectors are placed on the front and rear of the unit.
6.2.3
Connecting to Mains
1
Plug the Power Cable into the Power Inlet of the ILS500 and into the nearest socket.
6.2.4
Connecting Extra Features
When using the ports for Options, Status, Tooling and Control, make sure to mount the
connectors as shown below.
Notice
If you have purchased another type of probe than the Hand Probe P50,
refer to the manual for that probe. There may be other connections in
addition to the Probe Cable.
To disconnect the Probe, hold around the knurled part of the connector
and pull straight out.
Standard cable length is 3 m (10 ft.). Several different cable lengths are
available.
For more information, see on page 99.
