Page 86

86
Technical Data
ninb63e1-f (1410)
14.2
Pneumatic Specifications
Data rate
1200-115200 baud
Data bits
8
Stop bits
1
Parity
None
Flow control
None
Communication Ports
Compressed Air Supply
Pressure
Std Model
0.35–0.7 MPa
(3.4–6.9 bar)
(50–100 psi)
Reduced vacuum capacity below:
0.5 MPa
(4.8 bar)
(70 psi)
HP model
0.5–0.7 MPa
(4.8–6.9 bar)
(70–100 psi)
Peak Consumption
at 6 bar (87 psi)
240 l/min (508 SCFH)
Quality
Oil free and filtered to 5
μ
m
Dew point
Max 10°C (50°F)
Tracer Gas Supply
Composition
95% N
2
and 5% H
2
Pressure
Std Model
0.005–1.0 MPa
(0.05–10.0 bar)
(0.72–145 psi)
HP model
0.02–4.5 MPa
(0.2–45.0 Bar)
(3–652 psi)
Quality
Industrial grade purity (>95% purity)
Exhaust
Capacity in Exhaust Duct
Min 30 m
3
/h (1000 SCFH)
Dimensions of Hose Leading to
Duct
ID 25 mm (1 in.)
