ILS500 Description
13
ninb63e1-f (1410)
3
ILS500 Description
ILS500 is manually controlled using the START and STOP buttons and the menu
system of the touch panel. The screen also shows the steps of the test sequence
graphically and in plain text.
3.1
Front View
ILS500 Front View
1
Red lamp
2
Green lamp
3
ILS500 Touch panel
4
START button
5
STOP button
6
ISH2000
1
2
3
4
5
6
