2 pre evacuation – INFICON Sensistor ILS500 Leak Detection System User Manual
Page 48

48
Recipes
ninb63e1-f (1410)
Test Step
1
See Connection Step 1 - 3 above and follow the instructions.
9.3.2
Pre Evacuation
Test Step
Tooling Outputs
ON
Condition for starting test
and Tooling Inputs
Info
Delay
1
2
3
4
0.0
Pre Evacuation
Pre Evacuation Setpoint
Extended Pre Evacuation
Gas Locate if gross leak
Locate if Evacuated below
-0.70
0,0
-0.40
bar
s
bar
Pre Evacuation Setpoint
A value of -0.70 bar (-0.07 MPa, -10 psi) is
adequate for most applications. This creates 70%
vacuum.
Extended Pre Evacuation
To ensure a complete filling. Evacuation will
continue for the set time after Evacuation Level has
been attained.
Gas Locate if Gross Leak
If there is a need to locate a leak with a Hand
Probe even if pre evacuation fails. ILS500 will fill to
chosen pressure in Locating Pressure under
Tracer Gas Test.
Locate if Evacuated Below
Gas will be filled only if at least set value is
reached. Limits gas spillage through gross leaks.
