5 blockage test – INFICON Sensistor ILS500 Leak Detection System User Manual
Page 51

Recipes
51
ninb63e1-f (1410)
9.3.5
Blockage Test
Fill Setpoint
Desired tracer gas fill pressure.
Fill Timeout
Object will be rejected if Pressure Setpoint has not
been attained within this time.
Cancels the fill if the test object has a major leak,
opens, or if there are loose connections.
External Fill Regulation
If selected, this is the setpoint of fill pressure alarm.
Internal pressure regulation is disengaged and
pressure will be that of the gas supply line. ILS500
checks that fill pressure is above Pressure Setpoint
before proceeding to gas test step.
Pressure Unit
Select desired unit.
Notice
This test can only be performed if both test ports are used and connected
on either side of the possible blockage.
Blockage Test
Blockage Test Pressure
Blockage Test Time
0.50
2.0
bar
s
Blockage Test Pressure
Minimum pressure to be attained at Test Port 2
during Blockage Test time.
Blockage Test Time
Time within which Blockage Test Pressure must be
attained at Test Port 2.
