9 recipes, 1 recipe overview, Recipes – INFICON Sensistor ILS500 Leak Detection System User Manual
Page 44: Recipe overview, 9recipes
44
Recipes
ninb63e1-f (1410)
9
Recipes
A recipe is a collection of settings suited for a particular test setup. This is used to have
different settings for different test objects.
9.1
Recipe Overview
Click Settings >> Recipes to enter the three Recipe Setup menus.
Load Recipe
Save Recipe
Delete Recipe
Use Recipes
Choose at startup
Recipe Setup
Recipe Setup
Connect with recipe
Use from list
Factory Default
Keep Tooling in Test Step
Keep Pressure in Test Step
0
Import from USB
Export to USB
Recipe Setup
USB Memory connected
Use Recipes
Select the box to activate the recipe handling.
Choose at Startup
When power is switched on, the ILS500 prompts
the operator to choose recipe.
Load Recipe
Loads the parameters of chosen recipe.
A new window will open.
Save Recipe
Saves the current settings under chosen recipe
name.
A new window will open.
