Using the ILS500
41
ninb63e1-f (1410)
8.2
Run a Test
The ILS500 will communicate through the lamps and messages on the display.
8.2.1
Start Up
1
Turn the ILS500 on.
2
Wait for Ready to Start to show on the display.
3
Click Load Recipe and choose a preset recipe, or follow the instructions in the
section on page 45.
5
Tracer Gas Filling
Tracer gas filling before gas test.
6
Blockage Test
•
Reveals internal blockages in tested object.
•
Ensures that connection lines and test fixture are
correctly connected.
The test object is filled through Test Port 1 while the
pressure is recorded in Test Port 2. Practical for
testing e.g. capillaries etc.
7
Gross Leak Test 3-Gas
Pressure Decay Test
Performed in parallel with tracer gas test.
Can be used for integral testing in parallel with a more
sensitive gas test at selected points.
8
Tracer Gas Test
The main leak test. This test can be manual using a
Hand Probe or fully automatic using an Active Probe.
9
Gas Evacuation
For fast removal of tracer gas after test. Can also
include an efficient air purge.
10
Tooling Disconnection
Disconnection of test fixture.
Step
Comment
Notice
Several of the steps are optional and can be turned off.
Chosen settings can be saved as a Recipe. For more information, see on
page 44. It is also possible to combine two recipes in one test sequence.
Contact your local supplier for more information and individual settings.
Lamp
Status
Indication
Red
ON
Acknowledge a leak.
Tested object rejected.
General error.
Green
ON
Test sequence is over and the tested object
accepted.
Yellow
(START Button)
Flashing
ILS500 is in stand by.
ON
The test sequence is running.
