E T C S e t u p G u i d e
Paradigm Virtual Touchscreen
Paradigm Virtual Touchscreen Setup Guide Page 8 of 8 Electronic Theatre Controls, Inc.
Step 8: When the new event should recur, click the “Recurrence” tab.
Step 10: Select the “Start” tab in the dialog to set the event actions.
Step 12: Click [Ok] to close the wizard. The new event displays in the Timed Events list.
Edit Existing Event
Editing an existing event is very similar to adding a new event. Click the existing event from the Timed
Events list, then click [Edit]. The Timed Events wizard displays for selection including all of the pre-set
event data. Edit the event settings, then click [Ok] to close the wizard and return to the Timed Events
dialog.
Delete Existing Event
To delete an existing timed event, click the event in the Timed Events list, then click [Delete]. A dialog
displays requesting confirmation of whether you really want to delete the event. Click [Yes] to delete the
Timed Event and return to the Timed Events dialog.
Exit Timed Events Dialog
Click the [Exit] button on the bottom right of the display to exit the Timed Events dialog.
Step 9: Select the recurrence type from the “Type” drop
down. Additional settings are provided
depending on the types selected, be sure to
complete all options for the selection. For
example, if “Weekly” is selected, the following
options display:
Step 11: Select the event action from the “Action” drop
down. Additional settings are provided
depending on the selected action. Be sure to
complete all options for the selection. For
example, if “Space Flick Warn for Preset” is the
action selected, the following options display:
