Main lug support panel breaker position – ETC Unison Auxiliary Enclosure Series User Manual
Page 16
13
Unison Enclosure Installation
Main Lug Support Panel Breaker Position
The unit ships with the support panel in the top feed position (shifted to the bottom of the
AX). These positions are to comply with UL and NEC wire bending space requirements.
Step 1:
If you are bottom feeding the AX, loosen the 4 nuts from the sides of the
enclosure.
Step 2:
Reposition the support panel with the breaker on the main lugs to the top
position.
Step 3:
Tighten the nuts.
