background image

Whistle and Tweeter Installation Guide

Technical Specifications

MAN-WHTWIG (Ver. 1.604)

www.elmomc.com

58

Elmo now offers a 200 VDC maximum output rating selection of Whistle, according to the
following technical data:

Feature

Units

3/200

6/200

10/200

Minimum supply voltage

VDC

24

Nominal supply voltage

VDC

170

Maximum supply voltage

VDC

195

Maximum continuous power output

W

480

960

1600

Efficiency at rated power (at
nominal conditions)

%

> 99

Maximum output voltage

> 95% of DC bus voltage at f = 22 kHz

Auxiliary power supply

VDC

12 – 95 VDC (up to 2.5 VA inc. 5 V/200 mA for

encoder)

Amplitude sinusoidal/DC
continuous current

A

3

6

10

Sinusoidal continuous RMS current
limit (Ic)

A

2.12

4.24

7.07

Peak current limit

A

2 x Ic

Weight

g (oz)

50 g (1.8 ounces)

Dimensions

mm (in)

55 x 15 x 46.5 (2" x 0.6" x 1.8")

Digital in/Digital out/Analog in

6/2/1

Mounting method

PCB mount
