Whistle and Tweeter Installation Guide
MAN-WHTWIG (Ver. 1.604)
53
Chapter 4:
Technical Specifications
This chapter provides detailed technical information regarding the Whistle and Tweeter. This
includes its dimensions, power ratings, the environmental conditions under which it can be
used, the standards to which it complies and other specifications.
4.1. Features
The features of the Whistle and Tweeter determine how they control motion, as well as how
they process host commands, feedback and other input.
4.1.1.
Motion Control Modes
•
Current/Torque - up to 14 kHz sampling rate
•
Velocity -
up to 7 kHz sampling rate
•
Position -
up to 3.5 kHz sampling rate
4.1.2.
Advanced Positioning Control Modes
•
PTP, PT, PVT, ECAM, Follower, Dual Loop, Current Follower
•
Fast event capturing inputs
•
Fast output compare (OC)
•
Motion Commands: Analog current and velocity, pulse-width modulation (PWM)
current and velocity, digital (SW) and Pulse and Direction
4.1.3.
Advanced Filters and Gain Scheduling
•
“On-the-fly” gain scheduling of current and velocity
•
Velocity and position with “1-2-4” PIP controllers
•
Automatic commutation alignment
•
Automatic motor phase sequencing
4.1.4.
Fully Programmable
•
Third generation programming structure with motion commands - “Composer”
•
Event capturing interrupts
•
Event triggered programming
