Upload All
Select Upload All to upload the point configuration from the current gate-
way to the OIS. The individual point names will appear as asterisks (if no
name is entered in the database for the point) and will have to be
renamed. Status messages appear during the upload process.
To stop the upload procedure, press “command period” ( Á.).
Download One
Select Download One to download a single point configuration (whichever
point is selected) from the OIS to the current gateway. Status messages
appear during the download process. The gateway will then transfer the
configuration to the individual communication modules.
Upload One
Select Upload One to upload a selected single point’s configuration from
the current gateway to the OIS. The individual point name will appear as
an asterisk (if no name is entered in the database for the point) and will
have to be renamed. Status messages and prompts appear during the
upload process.
Clear Memory
Select Clear Memory to completely erase any information stored in the
current gateway’s non-volatile memory. This is usually done at the start of
the configuration of a new gateway.
Reset Module
Select Reset Module to initiate the equivalent of a power-up reset. This
“re-initializes” the module’s software.
This does not affect the module’s type code, configuration code, calibra-
tion gas setpoint or alarm setpoints.
Set GW Address
Sets the Modbus address for the gateway being configured by
EagleVision. This must match the DIP switch settings for Modbus address
on the gateway.
Get Voltage
Retrieves and displays the 24 vdc supply voltage level as measured at the
selected module.
To stop this process, press “command period” ( Á.).
Holding down the option key when selecting “Get Voltage” will allow
entry of a starting and ending node number allowing the voltage of a
specific group of nodes to be retrieved.
Update Aux GW
Sends updated configuration information to a selected auxiliary gateway.
Network Utilities
