3. The Point Configuration screen is displayed:
Point numbers 1 through 4 are reserved for the gateway.
4. Assign a configuration number to the current point:
a. Refer to the Eagle 2000 ™ System Configuration Matrix (form num-
ber 95-8453) to determine the configuration number for the
device.
b. Select the Config Number box to display the up and down scroll
arrows (located next to the Config Number box).
c. Enter the configuration number:
■ Use the up and down scroll arrows until the desired Config.
Number is displayed.
■ Select the “S” box next to the scroll arrows and enter the configu-
ration number in the Enter Number dialog box. Scroll through the
list using the arrows next to the configuration number. The infor-
mation for that type will be displayed.
5. Select Accept when all the point configuration values are
entered, or select Cancel to restore previous point configuration
data.
6. Enter a point name:
a. Select the point name box. The Enter Name/Title dialog box
appears.
b. Enter the desired point name (up to 48 characters).
c. Select Okay to accept the name or cancel to leave the existing
name.
2.23
95-8434
Point Configuration ( Á5)
A1793
